Energy Storage Converters 50kW 100kW 150kW 250kW 500kW Power Conversion System Built-in Isolation Transformer for Safety

Brand Name : 1stess

Model Number : Monet-1000

Place of Origin : China

MOQ : 1

Price : negotiable

Payment Terms : L/C,T/T

Supply Ability : 10 containers per month

Delivery Time : 60-90 days

Packaging Details : container

Output Frequency : 50/60Hz

Size : 1200*1000*2100mm

Communication Interface : S485 / CAN / Ethernet

Keyword : Power Conversion System

Protection level : IP21(Indoor);IP55(Outdoor)

System Voltage : 580~1000 V

Contact Now

Energy Storage Converters 50kW 100kW 150kW 250kW 500kW Power Conversion System Built-in Isolation Transformer for Safety


Make up by 50kW and 125kW energy storage power modules, support on or off grid mode, has transformer, has STS module to achieve≤10ms seamless switching. The series is suitable for the areas have power outage issues occasionally.
Realize:
1) Bidirectional conversion of DC and AC power (DC/AC module);
2) Seamless switching.
Actual application:
Convert photovoltaic DC power into AC power for load use, or connect to the mains to realize profit from electricity sales;
Convert the AC power of the mains into DC power and store it in energy storage batteries. When the mains power outage, the STS achieves switching to the energy storage batteries ≤10ms. This product is also suitable for AC side coupling applications.
Model
Monet-50TS
Monet-100TS
Monet-150TS
Monet-250TS
Monet-500TS
Operate voltage range
580~1000V
Fullload voltage range
625V-950V
Maximum DC current
110A
110A*2
110A*3
200A*2
200A*4
Input auantity
1
1
1
1
1
Adaptive battery
lithium/lead acid/Solar panel (MPPT)
On- Grid
Rated Max. AC power
50/55kW
100/110kW
150/165kW
250/275kW
500/550kW
Rated AC current
72A
144A
216A
180A*2
180A*4
Rated AC voltage
400VaC(-15%~+10%),3W+PE/3W+N+PE
Rated AC frequency
50/60Hz±5Hz
THDi
＜3%(Rated power)
Power Factor
-1leading to+1 lagging
Off- Grid
Rated AC voltage
400Vac, 50/60Hz
THDv
<3%(Linear load)
Unbalanced load capability
100%
Overload Capacity
110%: normal operation, 120%: 1 minute
Isolation mode
Isolation Transformer (Transformer inside cabinet)
Dimensions (W * D * H)
800*800*2100mm(Indoor)；900*1000*2100mm(Outdoor)
1200*1000*2100mm(Indoor)；1350*1000*2100mm(Outdoor)
Weight (approx)
550/630kg
730/820kg
910/990kg
1270/1390kg
2055/2175kg
Protection level
IP21(Indoor)；IP55(Outdoor)
Ambient temperature
-25℃ to +60℃ (derating above 45℃)
Altitude
3000m (> 3000m reduction)
Communication interface
RS485/CAN/Ethernet
Certificates
EN 61000-6-1/ EN 61000-6-2/ EN 61000-6-3
IEC 61000,IEC 62477-1:2012,IEC 61727,IEC 62116, GB /T 34120, GB /T 34133
Functional features Versatile:
With PQ, VF, VSG, MPPT, DC voltage source and other operating modes; With one-time frequency modulation/voltage regulation, VSG,
black start function;
It has the function of parallel and off-grid switching, and supports the function of multi-machine parallel connection.
Fast response:
The charging and discharging conversion time is not more than 40ms, and the response time is less than 30ms,
which meets the scheduling needs or frequency modulation project applications.
Convenient maintenance:
Modular rack design, energy storage battery can operate independently, convenient maintenance and good scalability.
Stable and reliable:
Integrated power frequency isolation transformer, with strong impact resistance and higher safety, is suitable for microgrid
systems that need to operate off-grid.
High efficiency and energy saving:
Three-level circuit design, high conversion efficiency, improve power utilization.
